Optical surface profilers
Optical surface profilers from Polytec are innovative, high-precision and non-contact tools for characterizing the surface topography in 3D. They are based on the principle of white-light interferometry, which is also known as coherent or vertical scanning interferometry or coherence radar. Thanks to their large vertical range, nanometer resolution and areal measurement, they are perfect for contactlessly measuring the flatness, step height and parallelism of large sample structures – on almost every material.
Surface profilers
White-light interferometers are optical 3D surface profilers and the ideal solution for inspecting functional surfaces with utmost precision and reliability. TopMap surface metrology systems measure form parameters like step-height, waviness, flatness and parallelism, as well as roughness and microstructures in all environments from research laboratories, close to and in production lines.
Capture, evaluate and analyze surface data
In addition to an intuitive operation of the topography measurement systems, the TMS measurement and analysis software enables easy filtering and analysing of your measurement data. For the automated analysis of routine measurement tasks, the open software architecture offers also a application-specific and user-configurable interface. You need even more functions? The TMS report packages additionally expand the already large range of functions of the TMS Software. Contact us!
Measurement Services
The range of Polytec measurement services available allows anyone to characterize surfaces of precision engineered products using our engineering services and system rentals. That way, you can make use of our ultra-modern measuring technology without investing in your a own instrument. We can also offer you our customer training sessions and application support services. Please do not hesitate to contact our PolyXperts team with any questions about our available instruments.
Technical Service
Optical measurement systems keep their value even after many years of use. Modularly structured Service will help you to maintain the equipment to be ready for use with its latest technical revision at any time. Therefore please ensure that your Polytec Systems are regularly serviced at your nearest Polytec Support Center. This ensures correct operation after many years in use just as accurately as at the very beginning of its service life. Dependent on your preferences we can perform the Service for your Topography Measurements Systems either onsite at your location or at one of our Service Centers. In the latter case we can even offer to arrange packing and transportation for you.
You will find Support Centers in Germany, USA, Singapore and Japan. As an ISO 9001 certified partner, we can provide all of the required Service for you. The basic modules of our Service are Calibration, Preventive Maintenance, Repair and Software Updates.
Optical 3D surface profilers
White-light interferometers are optical 3D surface profilers and the ideal solution for inspecting functional surfaces with utmost precision and reliability. TopMap surface metrology systems measure form parameters like step-height, waviness, flatness and parallelism, as well as roughness and microstructures in all environments from research laboratories, close to and in production lines.
Software
In addition to an intuitive operation of the topography measurement systems, the TMS measurement and analysis software enables easy filtering and analysing of your measurement data. For the automated analysis of routine measurement tasks, the open software architecture offers also a application-specific and user-configurable interface.
Measurement Services
The range of Polytec services available allows anyone to characterize surfaces of precision engineered products using our engineering services and system rentals. That way, you can make use of our ultra-modern measuring technology investing in your a own instrument. We can also offer you our customer training sessions and application support services.
Technical Service
Optical measurement systems keep their value even after many years of use. Modularly structured Service will help you to maintain the equipment to be ready for use with its latest technical revision at any time. Therefore please ensure that your Polytec Systems are regularly serviced at your nearest Polytec Support Center. This ensures correct operation after many years in use just as accurately as at the very beginning of its service life. Dependent on your preferences we can perform the Service for your Topography Measurements Systems either onsite at your location or at one of our Service Centers. In the latter case we can even offer to arrange packing and transportation for you.
TopMap Micro.View+
TopMap Micro.View+ is the next generation optical surface profiler in a modular design to reliably measure the most challenging analysis tasks regarding surface finish and microstructures with utmost precision. Focus Finder and Focus Tracker assist in keeping samples focused at all times, with fully motorized positioning units ready for automation. Find out more!
TopMap QC Package
A whole new package of smart features for quality control (QC) tasks are now available for the TopMap 3D surface profiling systems - the TopMap QC Package supports surface inspections especially in challenging production environments.
TopMap Micro.View
TopMap Micro.View is an easy to use and compact optical profiler. Choose Micro.View as the cost-effective quality control solution for surface analysis of precision-engineering, for inspecting roughness, microstructures and more surface details.
TopMap Pro.Surf+
The all-in-one 3D optical surface profiler from Polytec. The precision of a white-light interferometer, complemented by chromatic confocal sensors to overcome form deviations and any roughness determined with one device. Pro.Surf+ measures topography over a large area and, in so doing, characterizes structures with nanometer resolution.
TopMap Pro.Surf
Ideal for quick and precise 3D surface characterization. The areal measurement of the TopMap Pro.Surf ensure to not miss any details when inspecting your workpiece surface. Short measuring times and a large field-of-view characterize the TopMap Pro.Surf.
TopMap In.Line
The TopMap In.Line’s compact design means it can be easily integrated into the production line and quickly carries out checks on differently reflective surfaces. Steps, larger ripples or other surface structures do not pose any problems here.
TopMap Metro.Lab
Being a complete measuring station, the TopMap Metro.Lab is ideally suited to large-area topographies on almost all surfaces. Since it offers great value for money, it is also attractive for smaller companies with fewer tasks.
Operator Interface
Especially for close-to-manufacturing applications where multiple samples are handled, the software module QC Operator Interface guides the operator and greatly simplifies quality control (QC) of precision surfaces.
TMS Software
The TMS Software for Polytecs topography measurement systems of the TopMap series offers a wide range of features and options for quick and easy routine measurements but also for your extensive and detailed surface analysis.
TMS Viewer
Are you looking for a convenient way to quickly share your measurement results with your colleagues and project partners? TMS Viewer is the viewing tool for TopMap measurement systems, in case the full version of TMS Software is not installed.
Polytec Update
Polytec Update is a software tool that provides your Polytec products with the latest software releases and hotfixes. Polytec Update therefore always keeps you posted when there are updates for your Polytec measurement or desktop software – to ensure reliable measurement results and smooth working with Polytec products.
Engineering services and rentals
Our PolyXperts are looking forward to supporting you with measurement services- whether in our modern labs or at your premises. We’d be happy to guide and consult you at any stage. Besides outsourcing, ask for our rental equipment, expanding your capabilities.
Seminars and Training Sessions
We offer all users, from beginners, to specialists, the chance to refresh their specialist knowledge and to exchange ideas with our experts during technology days, in seminars and at user conferences.
Preventive Maintenance
Highly sophisticated optical measurement equipment needs some limited, but very precise care, in order to maintain the original equipment specifications and precision. It includes cleaning, realigning of the optics if needed, and if further needed, replacement of worn parts as well as maintenance of the mechanical units and functional tests.
Calibration
Calibration ensures validity of the measurement results and certifies the Polytec measuring instruments to close the loop with your ISO Standard and QM regulations. The System is calibrated by matching various sensitive signal ratios. Alignment and calibration will be carried out with certified calibration tools which also follow regular traceable calibration procedures in accordance with ISO standards.
Repair
In case a component of your Polytec System unexpectedly becomes defective we can provide fast and reliable repair with original spare parts, including maintenance of the entire system so that everything works flawlessly again. Standard spare parts we provide from stock. To keep your system up to the latest revisions, we supply parts with the latest improvements and firmware revisions included.
During the product life cycle we constantly improve the series and offer hardware or software upgrades. If you need any additional options or accessories for your current instrument, please contact us, as we may also offer suitable upgrades.
Service Packages
Choose from single service modules or complete packages:
Optical 3D surface profilers
White-light interferometers are optical 3D surface profilers and the ideal solution for inspecting functional surfaces with utmost precision and reliability. TopMap surface metrology systems measure form parameters like step-height, waviness, flatness and parallelism, as well as roughness and microstructures in all environments from research laboratories, close to and in production lines.
Software
In addition to an intuitive operation of the topography measurement systems, the TMS measurement and analysis software enables easy filtering and analysing of your measurement data. For the automated analysis of routine measurement tasks, the open software architecture offers also a application-specific and user-configurable interface.
Measurement Services
The range of Polytec services available allows anyone to characterize surfaces of precision engineered products using our engineering services and system rentals. That way, you can make use of our ultra-modern measuring technology investing in your a own instrument. We can also offer you our customer training sessions and application support services.
Technical Service
Optical measurement systems keep their value even after many years of use. Modularly structured Service will help you to maintain the equipment to be ready for use with its latest technical revision at any time. Therefore please ensure that your Polytec Systems are regularly serviced at your nearest Polytec Support Center. This ensures correct operation after many years in use just as accurately as at the very beginning of its service life. Dependent on your preferences we can perform the Service for your Topography Measurements Systems either onsite at your location or at one of our Service Centers. In the latter case we can even offer to arrange packing and transportation for you.
