Characterizing dynamics on solar modules
Throughout their service life, solar cells are exposed to an extremely wide range of weather conditions that not only cause thermal stresses, but varying dynamic stresses too. This is precisely why developers have a major goal: namely, to deliver the greatest possible level of stability and the longest possible operating time by means of design optimization. Material modeling and simulations help you to illustrate stress scenarios and processes for a photovoltaic module’s materials and components in a model – and, based on this, to develop and improve them in an appropriate way. You can predict both the service life and the mechanical properties for a newly developed material with a very high level of accuracy by combining various simulation methods with experimental investigations.
Measuring dynamic properties of solar modules
To get the material and structural parameters needed to do exactly that – take stiffness or damping, for example – all you have to do is measure the solar module’s dynamic properties. Scanning vibrometry, which allows you to easily determine resonance frequencies and deflection shapes, is ideally suited for this precise purpose. See the following comparison between calculated modes and measured ODS of a solar module.
Related products
VibroScan QTec Xtra 3D
VibroScan QTec Xtra 3D measures vibrations triaxially in a new way - without contact, full-field and with unprecedented precision. With its groundbreaking multi-path interferometry, QTec® sets new standards in terms of optical sensitivity and interference immunity. The Xtra, based on an infrared (SWIR) laser is characterized by the highest optical sensitivity to guarantee highly accurate measurements even on demanding technical surfaces. VibroScan QTec Xtra 3D ensures maximum portability through integrated data acquisition and signal generator up to 32 MHz.
VibroScan QTec Xtra
VibroScan QTec Xtra measures vibrations in a new way - without contact, full-field and with unprecedented precision. With its groundbreaking multi-path interferometry, QTec® sets new standards in terms of optical sensitivity and interference immunity. The Xtra, based on an infrared (SWIR) laser is characterized by the highest optical sensitivity to guarantee highly accurate measurements even on demanding technical surfaces. VibroScan QTec Xtra ensures maximum portability through integrated data acquisition and signal generator up to 32 MHz.
VibroFlex
With the modular laser vibrometer VibroFlex, Polytec presents the superior flexibility in optical vibration measurement with a modular sensor solution up to 24 MHz that adapts to your needs: Add microscope objectives for observing tiny structures or measure large samples like machinery or motors from a safe distance. Discover acoustics and vibration phenomena in research and product development for a faster time-to-market or use it for reliable in-line inspections. Learn about how the patented multi-path interferometry QTec® provides an always stable signal level, 20 dB better SNR for faster and clearer results without post-processing.
