自動車用途における表面計測技術
寸法公差は、製品の燃料効率・エネルギー効率、環境性能、耐久性に決定的な影響を及ぼします。シール面から駆動系、ショックアブソーバー、噴射システムに至るまで、数多くの用途が「試練に晒されています」。
絶対的な精度と全体像、すなわち3D空間パラメータが極めて重要であり、平坦度、平行度、形状パラメータ、表面パラメータ、高さ、段差の測定は不可欠です。これを保証するために何を用いるべきか?もちろん、Polytec の表面測定システムです!
当社の表面プロファイラー - お客様のニーズに応える幅広いラインナップ

マイクロプロファイラー
Micro.Viewシステムは、サブナノメートル領域の超高分解能測定向けに最適化されています。集光光学系と高い高さ分解能により、微細構造、表面仕上げ、材料分布を詳しく解析できます。わずかな偏差も見逃せない用途に適しています。

マクロプロファイラ
Pro.Surf は、大型部品やマルチパートトレイの平面度・段差・平行度を非接触でわずか数秒で検査します。衝突を防ぐテレセントリック光学系は穴の内部まで測定でき、生産現場が求める精度と再現性を実現します。

Roughness Tester
Roughness Testerは、Micro.Viewシリーズのエントリーモデルです。3D表面粗さ測定を最も低コストで始められます。Rパラメータ(線粗さ)からSパラメータ(面粗さ)へステップアップしましょう。
